This graph shows which files directly or indirectly include this file:

Data Structures
struct	material

struct	vertex

struct	element

struct	contam

Macros
#define	pi 3.14159265359

Functions
void	ReadInit ()

void	ReadDataFiles ()

void	AdjacentCells (int ln, int i, int j, int k)

void	Convertto2d ()

void	Convertto3d ()

void	DarcyVelocity ()

struct matr	MatrixProducts (double normxarea[][2], int number)

struct lb	DefineBoundaryAngle (int i, unsigned int edge_1, unsigned int edge_2, int f1, int coorf)

void	VelocityInteriorNode (double normxarea[][2], int i, int number, unsigned int indj[max_neighb], int vi)

void	VelocityExteriorNode (double normxarea[][2], int i, int number, unsigned int indj[max_neighb], struct lb lbound, int vi)

void	CheckNewCell ()

void	ParticleTrack ()

struct intcoef	CalculateWeights (int nn1, int nn2, int nn3)

void	SearchNeighborCells (int nn1, int nn2, int nn3)

int	InsideCell (unsigned int numc)

void	NeighborCells (int k)

void	PredictorStep ()

void	CorrectorStep ()

void	DefineTimeStep ()

int	CheckDistance ()

void	AcrossIntersection (int prevcell, int int1, int int2, int mixing_rule)

void	ChangeFracture (int cell_win)

struct posit3d	CalculatePosition3D ()

int	InitCell ()

int	InitPos ()

void	Moving2Center (int nnp, int cellnumber)

int	Moving2NextCell (int stuck, int k)

void	BoundaryCells ()

int	InitParticles_np (int k_current, int firstn, int lastn, int parts_fracture, int first_ind, int last_ind)

int	InitParticles_eq (int k_current, int firstn, int lastn, double parts_dist, int first_ind, int last_ind)

int	CornerVelocity (int i, int m1, int m2, int m3, int s1, int s2, int s3)

void	ReadBoundaryNodes ()

FILE *	OpenFile (char filen[120], char fileopt[2])

void	ReadFEHMfile (int nedges)

void	ReadPFLOTRANfile (int nedges)

void	WritingInit ()

void	Velocity3D ()

double	CalculateCurrentDT ()

int	Yindex (int nodenum, int np)

int	Xindex (int nodenum, int np)

int	CompleteMixingRandomSampling (double products[4], double speedsq[4], int indj, int int1, int indk)

int	StreamlineRandomSampling (double products[4], double speedsq[4], int indj, int int1, int indk, int neighborcellind[4], int neighborfracind[4], int prevfrac, int prevcell)

void	OutputVelocities ()

int	XindexC (int nodenum, int ii)

int	YindexC (int nodenum, int ii)

double	DefineAngle (double u1, double u2, double v1, double v2)

void	HalfPolygonVelocity (int i, int k, int fractn, int indc, unsigned int fractj[max_neighb])

struct posit3d	CalculateVelocity3D ()

void	BoundaryLine (int n1, int n2, int n3)

void	CheckGrid ()

int	BVelocityDirection (int b1, int b2)

double	InOutFlowCell (int indcell, int int1, double nposx, double nposy)

void	Moving2NextCellBound (int prevcell)

struct inpfile	Control_File (char fileobject[], int ctr)

struct inpfile	Control_Data (char fileobject[], int ctr)

void	ParticleOutput (int currentt, int frac_p)

struct inpfile	Control_Param (char fileobject[], int ctr)

void	FlowInWeight (int numbpart)

int	InitParticles_ones (int k_current, double inter_p[][4], int fracture, int parts_fracture, int ii, double thirdcoor, int zonenumb_in, int first_ind, int last_ind)

void	Coordinations2D ()

void	ReadAperture ()

void	InitInMatrix ()

double	TimeFromMatrix (double pdist)

void	FinalPosition ()

struct lagrangian	CalculateLagrangian (double xcurrent, double ycurrent, double zcurrent, double xprev, double yprev, double zprev)

void	OutputMarPlumDisp (int currentnum, char path[125])

int	String_Compare (char string1[], char string2[])

struct inpfile	Control_File_Optional (char fileobject[], int ctr)

double	TimeDomainRW (double time_advect)

int	InitParticles_flux (int k_current, int firstn, int lastn, double weight_p)

int	InitInWell (int nodepart)

Variables
char	maindir [125]

double	porosity

double	density

unsigned long int	timesteps

double	thickness

double	saturation

double	timeunit

char	controlfile [120]

double	totalFluxIn

unsigned int	pflotran

unsigned int	fehm

unsigned int	nnodes

unsigned int	ncells

unsigned int	nfract

unsigned int	max_neighb

unsigned int	npart

unsigned int	np

unsigned int	nzone_in

unsigned int *	nodezonein

unsigned int *	nodezoneout

unsigned int	flag_w

struct material *	fracture

struct vertex *	node

struct contam *	particle

struct element *	cell

Macro Definition Documentation

◆ pi

#define pi 3.14159265359

Definition at line 2 of file FuncDef.h.

Function Documentation

◆ AcrossIntersection()

void AcrossIntersection	(	int	prevcell,
		int	int1,
		int	int2,
		int	mixing_rule
	)

Particle is moving through intersection line

Definition at line 1784 of file TrackingPart.c.

References CalculateWeights(), cell, vertex::cells, ChangeFracture(), CompleteMixingRandomSampling(), vertex::coord_xy, vertex::fracture, element::fracture, contam::intcell, mixing_rule, node, element::node_ind, np, particle, contam::position, contam::prev_pos, StreamlineRandomSampling(), element::veloc_ind, vertex::velocity, intcoef::weights, XindexC(), and YindexC().

Referenced by CheckDistance().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ AdjacentCells()

void AdjacentCells	(	int	ln,
		int	in,
		int	jn,
		int	kn
	)

The function defines adjacent triangular cells for each node

Definition at line 485 of file ReadGridInit.c.

References cell, vertex::cells, vertex::fracts, vertex::fracture, element::fracture, fracture, node, and vertex::numneighb.

Referenced by ReadDataFiles().

Here is the caller graph for this function:

◆ BoundaryCells()

void BoundaryCells ( )

The function checks velocities at boundary nodes and fixes pathological cases.

In the rare event, when two velocity vectors are directed towards each other along the same cell edge, a particle will be stuck there. To avoid this situation, one of velocities is redirected along the edge with node associated with lower pressure value.

Definition at line 447 of file VelocityReconstruction.c.

References cell, vertex::cells, vertex::coord_xy, CornerVelocity(), DefineAngle(), fracture, vertex::indnodes, ncells, node, element::node_ind, vertex::numneighb, pi, vertex::pressure, element::veloc_ind, vertex::velocity, XindexC(), and YindexC().

Referenced by DarcyVelocity().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ BoundaryLine()

void BoundaryLine	(	int	n1,
		int	n2,
		int	n3
	)

◆ BVelocityDirection()

int BVelocityDirection	(	int	b1,
		int	b2
	)

◆ CalculateCurrentDT()

double CalculateCurrentDT ( )

Functions returns particle instanteneous time step

Definition at line 2239 of file TrackingPart.c.

References contam::cell, cell, node, element::node_ind, np, particle, vertex::timestep, element::veloc_ind, and contam::weight.

Referenced by CalculateWeights(), CheckDistance(), CorrectorStep(), and PredictorStep().

Here is the caller graph for this function:

◆ CalculateLagrangian()

struct lagrangian CalculateLagrangian	(	double	xcurrent,
		double	ycurrent,
		double	zcurrent,
		double	xprev,
		double	yprev,
		double	zprev
	)

Function calculates Lagrangian variables: tau and beta.

Definition at line 2634 of file TrackingPart.c.

References contam::cell, cell, vertex::cells, vertex::coord_xy, vertex::indnodes, node, element::node_ind, np, vertex::numneighb, particle, contam::position, contam::prev_pos, contam::time, Xindex(), and Yindex().

Referenced by ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ CalculatePosition3D()

struct posit3d CalculatePosition3D ( )

Function calculates 3D coordinates of current particle's position at 2D fracture plane

Definition at line 138 of file RotateFracture.c.

References CalculatePosition3D(), contam::cell, cell, posit3d::cord3, element::fracture, contam::fracture, fracture, np, particle, contam::position, and material::rot2mat.

Referenced by CalculatePosition3D(), ParticleOutput(), and ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ CalculateVelocity3D()

struct posit3d CalculateVelocity3D ( )

The function converts particle's 2D velocity vector to 3D velocity vector

Definition at line 190 of file RotateFracture.c.

References posit3d::cord3, vertex::fracture, fracture, maindir, nnodes, node, OpenFile(), material::rot3mat, and vertex::velocity.

Referenced by ParticleOutput(), and ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ CalculateWeights()

struct intcoef CalculateWeights	(	int	nn1,
		int	nn2,
		int	nn3
	)

Function calculates interpolation weights for velocity instanteneous particles velocity and time step.

Definition at line 1111 of file TrackingPart.c.

References CalculateCurrentDT(), CalculateWeights(), contam::cell, cell, FLAG_OUT, contam::fracture, node, element::node_ind, np, vertex::numneighb, particle, contam::position, contam::prev_pos, SearchNeighborCells(), contam::velocity, contam::weight, and intcoef::weights.

Referenced by AcrossIntersection(), CalculateWeights(), InOutFlowCell(), and InsideCell().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ ChangeFracture()

void ChangeFracture ( int cell_win )

This function recalculates particles coordinations at intersection lines. Particles XY coordinations at one fracture are recalculated to 3D positions and then new XY coordinations of an intersecting fracture are defined.

Definition at line 138 of file RotateFracture.c.

Referenced by AcrossIntersection(), and InOutFlowCell().

Here is the caller graph for this function:

◆ CheckDistance()

int CheckDistance ( )

Function checks the distance from particle to intersection line when particles is located at the intersection triangular cell

Definition at line 1474 of file TrackingPart.c.

References AcrossIntersection(), CalculateCurrentDT(), contam::cell, cell, vertex::cells, CheckNewCell(), vertex::coord_xy, vertex::fracture, fracture, vertex::indnodes, InOutFlowCell(), mixing_rule, no_out, node, element::node_ind, np, vertex::numneighb, particle, ParticleOutput(), contam::position, PredictorStep(), contam::prev_pos, t, t_adv, t_adv0, contam::t_adv_diff, contam::t_diff, tdrw, tdrw_o, contam::time, timediff, TimeDomainRW(), Xindex(), and Yindex().

Referenced by ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ CheckGrid()

void CheckGrid ( )

The function checks the grid: looking for nodes that are defined as internal or external, but belong to two fractures and should be defined as interface nodes

Definition at line 965 of file ReadGridInit.c.

References fracture, nnodes, node, and vertex::numneighb.

Referenced by main().

Here is the caller graph for this function:

◆ CheckNewCell()

void CheckNewCell ( )

Function performs a check, did particle move to a new triangular cell during last time step or stayed at the same cell

Definition at line 1111 of file TrackingPart.c.

Referenced by CheckDistance(), and ParticleTrack().

Here is the caller graph for this function:

◆ CompleteMixingRandomSampling()

int CompleteMixingRandomSampling	(	double	products[4],
		double	speedsq[4],
		int	indj,
		int	int1,
		int	indk
	)

Particle motion at a fracture intersection is determined by the streamline routing rule Arg 1: Cross product to define outgoing and incoming cells. Vector contains value for each cell at the intersection Arg 2: Vector of the speed squared for each cell at the intersection Arg 3: index of current cell in int1 node list Arg 4: int1 is the index of the node of the incoming cell that lies on the intersection Arg 5: indk gives the position in the list of the 4 intersection cells that is previous cell Return: The Exit cell at the intersection

Definition at line 2089 of file TrackingPart.c.

References vertex::cells, and node.

Referenced by AcrossIntersection().

Here is the caller graph for this function:

◆ Control_Data()

struct inpfile Control_Data	(	char	fileobject[],
		int	ctr
	)

The function reads control file with input parameters to dfnTrans; returns input parameter value. If the parameter is not defined in the control file, the program is terminated.

Definition at line 1089 of file ReadGridInit.c.

Referenced by InitPos(), main(), and ReadBoundaryNodes().

Here is the caller graph for this function:

◆ Control_File()

struct inpfile Control_File	(	char	fileobject[],
		int	ctr
	)

The function reads control file with input parameters to dfnTrans; returns the file name and/or input parameter value. If the parameter is not defined in the control file, the program is terminated.

Definition at line 965 of file ReadGridInit.c.

Referenced by InitInMatrix(), InitPos(), main(), OutputMarPlumDisp(), ParticleTrack(), ReadAperture(), ReadBoundaryNodes(), ReadDataFiles(), ReadFEHMfile(), ReadInit(), and ReadPFLOTRANfile().

Here is the caller graph for this function:

◆ Control_File_Optional()

struct inpfile Control_File_Optional	(	char	fileobject[],
		int	ctr
	)

The function reads control file with input parameters to dfnTrans; returns the file name and/or input parameter value. This function is called for the optional parameters only. If the parameter is not defined in the control file, the default value is used.

Definition at line 965 of file ReadGridInit.c.

Referenced by InitPos(), ParticleTrack(), and ReadInit().

Here is the caller graph for this function:

◆ Control_Param()

struct inpfile Control_Param	(	char	fileobject[],
		int	ctr
	)

The function reads control file with input parameters to dfnTrans; returns input parameter value. If the parameter is not defined in the control file, the program is terminated.

Definition at line 1089 of file ReadGridInit.c.

Referenced by InitPos(), main(), ParticleTrack(), and TimeFromMatrix().

Here is the caller graph for this function:

◆ Convertto2d()

void Convertto2d ( )

The function uses rotation matrix and fracture's normal vector to rotate fracture from its position in 3D to XY plane

if node belongs to intersection, belongs to two fractures

Definition at line 17 of file RotateFracture.c.

References vertex::coord, vertex::coord_xy, vertex::fracture, fracture, nfract, nnodes, node, material::nvect_xy, pi, material::rot2mat, material::rot3mat, and material::theta.

Referenced by main().

Here is the caller graph for this function:

◆ Convertto3d()

void Convertto3d ( )

The function uses rotation matrix to rotate fracture from its position in XY plane to 3D domain

Definition at line 100 of file RotateFracture.c.

References fracture, nfract, material::nvect_z, pi, material::rot3mat, and material::theta.

Referenced by main().

Here is the caller graph for this function:

◆ Coordinations2D()

void Coordinations2D ( )

The function outputs 2D coordinations of nodes: every fracture into separate file. Those files are used as input to gstat for length correlation of aperture.

Definition at line 280 of file RotateFracture.c.

References vertex::coord_xy, fracture, nfract, nnodes, node, and OpenFile().

Here is the call graph for this function:

◆ CornerVelocity()

int CornerVelocity	(	int	i,
		int	m1,
		int	m2,
		int	m3,
		int	s1,
		int	s2,
		int	s3
	)

The Function identifies pathologycal cases at corner of fracture boundary. The angle between velocity on corner node and velocities/edges on surrounding boundary nodes are calculated. Then, if velocity is pointing outside of fracture, turns the velocity direction along the fracture edge.

Definition at line 658 of file VelocityReconstruction.c.

References vertex::coord_xy, DefineAngle(), node, pi, vertex::velocity, XindexC(), and YindexC().

Referenced by BoundaryCells().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ CorrectorStep()

void CorrectorStep ( )

Corrector step in Predictor-Corrector technique. Function calculates new particle position using calculated velocity in Predictor step.

Definition at line 1408 of file TrackingPart.c.

References CalculateCurrentDT(), contam::cell, cell, element::node_ind, np, particle, contam::position, contam::prev_pos, element::veloc_ind, and contam::velocity.

Referenced by ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ DarcyVelocity()

void DarcyVelocity ( )

Function performs Darcy's velocity reconstruction (main function of Darcy velocities reconstruction procedure) using linear least square algorithm. Flow solver provides flow fluxes on each edge of control volume cells. Velocity on each control volume cell center (each node) is reconstructed using flow fluxes.

Velocity of interior and interior-interface nodes is reconstructed according to Eq.5 (Painter,2011); exterior node' velocity according to Eq.7 (Painter, 2011)

Function makes a loop over all nodes and calls functions for velocity reconstruction depending of type of the node (external, internal, internal-interface, external interface)

Definition at line 29 of file VelocityReconstruction.c.

References BoundaryCells(), vertex::coord_xy, DefineBoundaryAngle(), fehm, vertex::fracture, fracture, HalfPolygonVelocity(), vertex::indnodes, max_neighb, nnodes, node, vertex::numneighb, pflotran, vertex::velocity, VelocityExteriorNode(), and VelocityInteriorNode().

Referenced by main().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ DefineAngle()

double DefineAngle	(	double	u1,
		double	u2,
		double	v1,
		double	v2
	)

Function defines an angle between two edges of voronoy cell

Definition at line 347 of file VelocityReconstruction.c.

References lb::angle.

Referenced by BoundaryCells(), CornerVelocity(), and ParticleOutput().

Here is the caller graph for this function:

◆ DefineBoundaryAngle()

struct lb DefineBoundaryAngle	(	int	i,
		unsigned int	edge_1,
		unsigned int	edge_2,
		int	f1,
		int	coorf
	)

The function defines angle between two edges of a boundary cell and return the result. The angle is used in flow velocity reconstruction on fracture edge.

Definition at line 214 of file VelocityReconstruction.c.

References fracture, maindir, nfract, nnodes, node, and vertex::velocity.

Referenced by DarcyVelocity(), and HalfPolygonVelocity().

Here is the caller graph for this function:

◆ DefineTimeStep()

void DefineTimeStep ( )

Function performs a loop through all the nodes in the mesh and defines a time step at each node. The time step of particles will be interpolated from time steps defined at each node.

Definition at line 1447 of file TrackingPart.c.

References nnodes, node, vertex::timestep, and vertex::velocity.

Referenced by main().

Here is the caller graph for this function:

◆ FinalPosition()

void FinalPosition ( )

Function calculates particles final position at out-flow boundary

Definition at line 2634 of file TrackingPart.c.

Referenced by ParticleTrack().

Here is the caller graph for this function:

◆ FlowInWeight()

void FlowInWeight ( int numberpart )

Function calculates particle's in-flow flux weight. Used in option #1, #2, #3.

Definition at line 747 of file InitialPartPositions.c.

References contam::cell, cell, contam::fl_weight, InitCell(), node, element::node_ind, np, vertex::numneighb, particle, and contam::weight.

Referenced by ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ HalfPolygonVelocity()

void HalfPolygonVelocity	(	int	i,
		int	k,
		int	fractn,
		int	indc,
		unsigned int	fractj[max_neighb]
	)

Velocity reconstruction on an intersection node. In this case, the control volume cell is devided onto two polygons by intersection line. The velocity reconstruction is performed on each part of control volume cell at intersection.

Definition at line 806 of file VelocityReconstruction.c.

References vertex::area, cell, vertex::cells, vertex::coord_xy, DefineBoundaryAngle(), fehm, fracture, vertex::indnodes, max_neighb, node, pflotran, vertex::type, vertex::typeN, element::veloc_ind, VelocityExteriorNode(), and VelocityInteriorNode().

Referenced by DarcyVelocity().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ InitCell()

int InitCell ( )

Function performs a search to find cell Id where the particle was initially placed.

Definition at line 542 of file InitialPartPositions.c.

References vertex::cells, InsideCell(), node, nodezonein, vertex::numneighb, and nzone_in.

Referenced by FlowInWeight(), and ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ InitInMatrix()

void InitInMatrix ( )

Function performs data reading from files for Option #5, init_matrix. In this option particles are placed at random positions in matrix, the time to move from initial position to nearest fracture is calculated in function TimeFromMatrix.

Input files ParticleInitCoordR.dat and ClosestNodeR.inp provide particles initial positions at matrix and te closes node ID at DFN mesh, respectively.

Definition at line 832 of file InitialPartPositions.c.

References contam::cell, Control_File(), vertex::coord, vertex::coord_xy, inpfile::filename, contam::fl_weight, vertex::fracture, contam::fracture, contam::intcell, node, npart, OpenFile(), particle, contam::position, contam::pressure, contam::prev_pos, contam::time, TimeFromMatrix(), contam::velocity, and contam::weight.

Referenced by InitPos().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ InitInWell()

int InitInWell ( int nodepart )

Definition at line 1028 of file InitialPartPositions.c.

References vertex::aperture, contam::cell, vertex::coord_xy, contam::fl_weight, vertex::fracture, contam::fracture, node, nodezonein, nzone_in, particle, contam::position, contam::pressure, contam::time, and contam::velocity.

Referenced by InitPos().

Here is the caller graph for this function:

◆ InitParticles_eq()

int InitParticles_eq	(	int	k_current,
		int	firstn,
		int	lastn,
		double	parts_dist,
		int	first_ind,
		int	last_ind
	)

Function defines particles initial positions at a single fracture edge, using calculated before distance between particles. Option #2, init_eqd.

Definition at line 623 of file InitialPartPositions.c.

References vertex::coord_xy, contam::fl_weight, vertex::fracture, contam::fracture, contam::intcell, node, npart, particle, contam::position, contam::pressure, contam::time, and contam::velocity.

Referenced by InitPos().

Here is the caller graph for this function:

◆ InitParticles_flux()

int InitParticles_flux	(	int	k_current,
		int	first_ind,
		int	last_ind,
		double	weight_p
	)

Function defines particle's initial positions at single fracture edge in Option #6. Particles are placed according to input flux weights. In this case, all the particles have the same flux weight, but number of particles per fracture edge depends on in-flow flux of this fracture.

Definition at line 939 of file InitialPartPositions.c.

References contam::cell, vertex::coord_xy, density, contam::fl_weight, vertex::flux, vertex::fracture, contam::fracture, contam::intcell, node, nodezonein, np, npart, vertex::numneighb, particle, contam::position, contam::pressure, contam::time, and contam::velocity.

Referenced by InitPos().

Here is the caller graph for this function:

◆ InitParticles_np()

int InitParticles_np	(	int	k_current,
		int	firstnd,
		int	lastnd,
		int	parts_fracture,
		int	first_ind,
		int	last_ind
	)

Function defines particle's initial positions on a single fracture edge. Option #1, init_nf

Definition at line 578 of file InitialPartPositions.c.

References vertex::coord_xy, contam::fl_weight, vertex::fracture, contam::fracture, contam::intcell, node, nodezonein, npart, particle, contam::position, contam::pressure, contam::time, and contam::velocity.

Referenced by InitPos().

Here is the caller graph for this function:

◆ InitParticles_ones()

int InitParticles_ones	(	int	k_current,
		double	inter_p[][4],
		int	fracture_n,
		int	parts_fracture,
		int	ii,
		double	thirdcoor,
		int	zonenumb_in,
		int	first_ind,
		int	last_ind
	)

Function defines particles initial positions in option #3, where user defines region at in-flow boundary face for particles.

Definition at line 668 of file InitialPartPositions.c.

References contam::fl_weight, contam::fracture, fracture, contam::intcell, npart, particle, contam::position, contam::pressure, material::rot2mat, contam::time, and contam::velocity.

Referenced by InitPos().

Here is the caller graph for this function:

◆ InitPos()

int InitPos ( )

Function defines the required option of particles initial positions defined at input control file; calculates number of particles, allocates memory.

First option init_nf: equal number of particles on every boundary edge regardless of edge length

Second option init_eqd: calculate total length of boundary edges; define the distance between particles and place particles equidistant from each other on all edges

Third option init_oneregion: user specifies a region and all particles start from the fracture edges that located inside the region

Fourth option init_random: particles will be set randomly over all fractures surfaces; in this case the particles are weighted acoording to the aperture

5th option init_matrix: particles are set randomly in rock matrix, their time from initial positions is calculated, then particles move through fractures to out-flow boundary. This option requires preprocessing; the script RandomPositGener.py will provide necessary input files

Sixth option init_flux: place particles according to input fluxes. Each particle has the same flux weight. The number of particles are placed propportionally to inflow flux on each cell and fracture edge.

Definition at line 21 of file InitialPartPositions.c.

References vertex::aperture, contam::cell, cell, Control_Data(), Control_File(), Control_File_Optional(), Control_Param(), vertex::coord, inpfile::filename, contam::fl_weight, inpfile::flag, flag_w, vertex::fracture, element::fracture, contam::fracture, fracture, InitInMatrix(), InitInWell(), InitParticles_eq(), InitParticles_flux(), InitParticles_np(), InitParticles_ones(), InsideCell(), Moving2Center(), ncells, node, element::node_ind, nodezonein, npart, nzone_in, inpfile::param, particle, contam::pressure, contam::time, totalFluxIn, and contam::velocity.

Referenced by ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ InOutFlowCell()

double InOutFlowCell	(	int	indcell,
		int	int1,
		double	nposx,
		double	nposy
	)

Function defines if velocities on cell vertices pointing in or out of intersection line

Definition at line 1730 of file TrackingPart.c.

References CalculateWeights(), contam::cell, cell, ChangeFracture(), vertex::coord_xy, contam::fracture, node, element::node_ind, np, particle, contam::position, element::veloc_ind, vertex::velocity, intcoef::weights, XindexC(), and YindexC().

Referenced by CheckDistance().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ InsideCell()

int InsideCell ( unsigned int numc )

Function checks if particle is in the cell (numc is cell ID)

Definition at line 1324 of file TrackingPart.c.

References CalculateWeights(), contam::cell, cell, contam::intcell, node, element::node_ind, np, particle, contam::weight, and intcoef::weights.

Referenced by InitCell(), InitPos(), Moving2Center(), and NeighborCells().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ MatrixProducts()

struct matr MatrixProducts	(	double	normxarea[][2],
		int	number
	)

Function performs matrix dot product (GTG)-1 and returns the result.

Definition at line 214 of file VelocityReconstruction.c.

Referenced by VelocityExteriorNode(), and VelocityInteriorNode().

Here is the caller graph for this function:

◆ Moving2Center()

void Moving2Center	(	int	nnp,
		int	cellnumber
	)

Function moves particle to the center of the same cell

Definition at line 2175 of file TrackingPart.c.

References cell, vertex::coord_xy, InsideCell(), node, element::node_ind, particle, contam::position, Xindex(), and Yindex().

Referenced by InitPos(), Moving2NextCell(), and Moving2NextCellBound().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ Moving2NextCell()

int Moving2NextCell	(	int	stuck,
		int	k
	)

Functions performs the movement of particle from one cell to the center of neighbouring cell.

Definition at line 2198 of file TrackingPart.c.

References contam::cell, cell, vertex::cells, fracture, Moving2Center(), node, np, and particle.

Here is the call graph for this function:

◆ Moving2NextCellBound()

void Moving2NextCellBound ( int prevcell )

In the pathological rare case, when particle is out of fracture, the function is called and it's moving particle to internal cell

Definition at line 2286 of file TrackingPart.c.

References contam::cell, cell, vertex::cells, fracture, Moving2Center(), node, element::node_ind, np, and particle.

Referenced by ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ NeighborCells()

void NeighborCells ( int k )

Function checks neighboring cells to find a particle

Definition at line 1426 of file TrackingPart.c.

References vertex::cells, fracture, InsideCell(), node, np, and particle.

Referenced by SearchNeighborCells().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ OpenFile()

FILE* OpenFile	(	char	filen[120],
		char	fileopt[2]
	)

The function opens file for reading or writing. If error - the program is terminated.

Definition at line 664 of file ReadGridInit.c.

Referenced by CalculateVelocity3D(), Coordinations2D(), InitInMatrix(), OutputMarPlumDisp(), ParticleOutput(), ParticleTrack(), ReadAperture(), ReadBoundaryNodes(), ReadDataFiles(), ReadFEHMfile(), ReadInit(), ReadPFLOTRANfile(), and WritingInit().

Here is the caller graph for this function:

◆ OutputMarPlumDisp()

void OutputMarPlumDisp	(	int	currentnum,
		char	path[125]
	)

This function is used when particles trajectories should be output in format that MARFA and/or PLUMECALC codes will be able to read and process.

Definition at line 19 of file output.c.

References cell, Control_File(), inpfile::filename, maindir, marfa, OpenFile(), plumec, timeunit, and traj_o.

Referenced by ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ OutputVelocities()

void OutputVelocities ( )

This function is called to output velocities on nodes in the order of fractture IDs. The output can be used to visualise flow field of 2D reconstructed Darcy velocities in 3D simulation domain

Definition at line 214 of file VelocityReconstruction.c.

◆ ParticleOutput()

void ParticleOutput	(	int	currentt,
		int	fract_p
	)

The function of particles trajectories outputs. Function is called at every intersection and outputs to file at each segment of particles trajectory: from intersection to intersection. The curvature of the trajectory is defined and dictate number of time steps for outputs (unless user requested every time step output).

Definition at line 2367 of file TrackingPart.c.

References vertex::aperture, avs_o, tempout::betap, CalculatePosition3D(), CalculateVelocity3D(), contam::cell, cell, tempout::cellp, posit3d::cord3, curv_o, DefineAngle(), contam::fracture, fracture, tempout::fracturep, tempout::length_t, maindir, no_out, node, element::node_ind, nodeID, np, OpenFile(), particle, pi, contam::position, tempout::position2d, tempout::position3d, contam::pressure, tempout::pressure, t, tempdata, tfile, contam::time, timecounter, tempout::timep, tempout::times, traj_o, and tempout::velocity3d.

Referenced by CheckDistance(), and ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ ParticleTrack()

void ParticleTrack ( )

The main driving function of particles tracking procedure.

The all necessary options for particle tracking and for the outputs are read from input control file.
The subroutine for particle initial positions is called.
External loop on paticles is organised. One particle at a time.
Internal loop on time steps, where particles are mobing through fracture network. 4.1 Predictor -corrector technique is used for particles to move through fractures. 4.2 Complete mixing or streamline routing rule (defined by user) are used on intersections. 4.3 Particles data outputs.

Definition at line 66 of file TrackingPart.c.

References all_out, vertex::aperture, avs_o, tempout::betap, lagrangian::betta, CalculateLagrangian(), CalculatePosition3D(), CalculateVelocity3D(), contam::cell, cell, tempout::cellp, CheckDistance(), CheckNewCell(), Control_File(), Control_File_Optional(), Control_Param(), vertex::coord, posit3d::cord3, CorrectorStep(), curv_o, disp_o, inpfile::filename, FinalPosition(), contam::fl_weight, inpfile::flag, FLAG_OUT, flag_w, FlowInWeight(), frac_o, vertex::fracture, contam::fracture, fracture, tempout::fracturep, InitCell(), InitPos(), lagrangian::initx, lagrangian::inity, lagrangian::initz, lagvariable, tempout::length_t, maindir, marfa, mixing_rule, Moving2NextCellBound(), nfract, no_out, node, element::node_ind, nodeID, nodezonein, nodezoneout, np, OpenFile(), OutputMarPlumDisp(), inpfile::param, particle, ParticleOutput(), plumec, contam::position, tempout::position2d, tempout::position3d, PredictorStep(), contam::pressure, tempout::pressure, String_Compare(), t, t_adv, t_adv0, contam::t_adv_diff, contam::t_diff, lagrangian::tau, tdrw, tdrw_diffcoeff, tdrw_lambda, tdrw_limited, tdrw_o, tdrw_porosity, tempdata, tfile, contam::time, timecounter, timediff, TimeDomainRW(), tempout::timep, tempout::times, timesteps, timeunit, traj_o, and tempout::velocity3d.

Referenced by main().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ PredictorStep()

void PredictorStep ( )

Predictor step in Predictor-Corrector technique. Function calculates new velocities and new particle position.

Definition at line 1383 of file TrackingPart.c.

References CalculateCurrentDT(), contam::cell, cell, node, element::node_ind, np, particle, contam::position, vertex::pressure, contam::pressure, contam::prev_pos, element::veloc_ind, contam::velocity, vertex::velocity, and contam::weight.

Referenced by CheckDistance(), and ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ ReadAperture()

void ReadAperture ( )

The function reads apertures of fractures in DFN. Aperture can be defined for each fracture or for every node/cell, representing internal heterogeneity.

Definition at line 1203 of file ReadGridInit.c.

References vertex::aperture, Control_File(), inpfile::filename, vertex::fracture, fracture, nfract, nnodes, node, and OpenFile().

Referenced by ReadDataFiles().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ ReadBoundaryNodes()

void ReadBoundaryNodes ( )

The functions reads node's IDs assigned to in-flow and out-flow boundaries. the total input flow flux is calculated.

Definition at line 526 of file ReadGridInit.c.

References Control_Data(), Control_File(), density, inpfile::filename, inpfile::flag, vertex::flux, maindir, node, nodezonein, nodezoneout, vertex::numneighb, nzone_in, OpenFile(), totalFluxIn, and vertex::typeN.

Referenced by main().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ ReadDataFiles()

void ReadDataFiles ( )

The function reads DFN mesh from inp and stor files

if no aperture file specified, the aperture of all fractures will be equal to thickness value

Definition at line 155 of file ReadGridInit.c.

References AdjacentCells(), vertex::aperture, vertex::area, cell, vertex::cells, Control_File(), fehm, inpfile::filename, material::firstcell, material::firstnode, vertex::flux, vertex::fracts, vertex::fracture, element::fracture, fracture, vertex::indnodes, material::lastnode, max_neighb, ncells, nfract, nnodes, node, material::numbcells, vertex::numneighb, OpenFile(), pflotran, ReadAperture(), ReadFEHMfile(), ReadPFLOTRANfile(), thickness, vertex::type, vertex::typeN, and element::veloc_ind.

Referenced by main().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ ReadFEHMfile()

void ReadFEHMfile ( int nedges )

The function opens and reads FEHM outputs; read in flow fluxes and cell volumes.

Definition at line 796 of file ReadGridInit.c.

References Control_File(), inpfile::filename, max_neighb, nnodes, node, OpenFile(), and vertex::pressure.

Referenced by ReadDataFiles().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ ReadInit()

void ReadInit ( )

The function reads total number of nodes, triangular cells, fractures in DFN mesh. The memory is allocated for data structures: NODE, CELL, FRACTURE

Definition at line 16 of file ReadGridInit.c.

References vertex::area, cell, vertex::cells, Control_File(), Control_File_Optional(), inpfile::filename, inpfile::flag, vertex::flux, vertex::fracts, fracture, vertex::indnodes, max_neighb, ncells, nfract, nnodes, node, material::nvect_xy, material::nvect_z, OpenFile(), material::theta, and vertex::type.

Referenced by main().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ ReadPFLOTRANfile()

void ReadPFLOTRANfile ( int nedges )

The function opens and reads PFLOTRAN files, read in flow fluxes, areas, pressure.

Definition at line 677 of file ReadGridInit.c.

References vertex::aperture, vertex::area, Control_File(), density, inpfile::filename, inpfile::flag, vertex::flux, nnodes, node, vertex::numneighb, OpenFile(), vertex::pressure, and vertex::pvolume.

Referenced by ReadDataFiles().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ SearchNeighborCells()

void SearchNeighborCells	(	int	nn1,
		int	nn2,
		int	nn3
	)

Function performs a search of neighbouring cells of current particles position.

Definition at line 1285 of file TrackingPart.c.

References cell, NeighborCells(), np, and particle.

Referenced by CalculateWeights().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ StreamlineRandomSampling()

int StreamlineRandomSampling	(	double	products[4],
		double	speedsq[4],
		int	indj,
		int	int1,
		int	indk,
		int	neighborcellind[4],
		int	neighborfracind[4],
		int	prevfrac,
		int	prevcell
	)

Particle motion at a fracture intersection is determined by the streamline routing rule Arg 1: Cross product to define outgoing and incoming cells. Vector contains value for each cell at the intersection Arg 2: Vector of the speed squared for each cell at the intersection Arg 3: index of current cell in int1 node list Arg 4: int1 is the index of the node of the incoming cell that lies on the intersection Arg 5: indk gives the position in the list of the 4 intersection cells that is previous cell Arg 6: Vector of the indicies for the 4 neighboring cells Arg 7: Vector of the fracture index for the 4 neighboring cells Arg 8: Fracture a particle is coming from Arg 9: Cell index a particle is coming from Return: The Exit cell at the intersection

Definition at line 1901 of file TrackingPart.c.

References cell, vertex::cells, fracture, and node.

Referenced by AcrossIntersection().

Here is the caller graph for this function:

◆ String_Compare()

int String_Compare	(	char	string1[],
		char	string2[]
	)

The finction performs a string comparison, used in the control file reading.

Definition at line 1089 of file ReadGridInit.c.

Referenced by main(), and ParticleTrack().

Here is the caller graph for this function:

◆ TimeDomainRW()

double TimeDomainRW ( double time_advect )

Time Domain Random Walk (TDRW) procedure to account for matrix diffusion. Returns a diffusion time of particle per fracture. This function is called at each intersection.

Details on the method can be found in

Hyman, Jeffrey D., Harihar Rajaram, Shriram Srinivasan, Nataliia Makedonska, Satish Karra, Hari Viswanathan, and Gowri Srinivasan. "Matrix Diffusion in Fractured Media: New Insights Into Power Law Scaling of Breakthrough Curves." Geophysical Research Letters 46, no. 23 (2019): 13785-13795.

Definition at line 2769 of file TrackingPart.c.

References vertex::aperture, contam::cell, cell, material::firstnode, contam::fracture, fracture, node, element::node_ind, np, particle, pi, tdrw_diffcoeff, tdrw_lambda, tdrw_limited, tdrw_porosity, and timediff.

Referenced by CheckDistance(), and ParticleTrack().

Here is the caller graph for this function:

◆ TimeFromMatrix()

double TimeFromMatrix ( double pdist )

Option #5. Estimation of travel time of particles moving from matrix to the closest fracture.

Definition at line 913 of file InitialPartPositions.c.

References Control_Param(), inpfile::param, pi, and timeunit.

Referenced by InitInMatrix().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ Velocity3D()

void Velocity3D ( )

Recalculates 2D velocities at XY fracture plane to 3D velocties in the simulation domain. This procedure is not used for particle tracking, but can be used for velocity field visualization.

Definition at line 190 of file RotateFracture.c.

Referenced by main().

Here is the caller graph for this function:

◆ VelocityExteriorNode()

void VelocityExteriorNode	(	double	norm_xarea[][2],
		int	i,
		int	number,
		unsigned int	indj[max_neighb],
		struct lb	lbound,
		int	vi
	)

The function reconstructs Darcy velocity on exterior (boundary) node

Definition at line 391 of file VelocityReconstruction.c.

References density, vertex::flux, lb::length_b, matr::matinv, matr::matrinvG, MatrixProducts(), node, lb::norm, porosity, timeunit, and vertex::velocity.

Referenced by DarcyVelocity(), and HalfPolygonVelocity().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ VelocityInteriorNode()

void VelocityInteriorNode	(	double	normx_area[][2],
		int	i,
		int	number,
		unsigned int	indj[max_neighb],
		int	vi
	)

The function reconstructs Darcy velocity on interior cell center, at interior node

Definition at line 356 of file VelocityReconstruction.c.

References density, vertex::flux, matr::matinv, matr::matrinvG, MatrixProducts(), node, porosity, timeunit, and vertex::velocity.

Referenced by DarcyVelocity(), and HalfPolygonVelocity().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ WritingInit()

void WritingInit ( )

Functions write the data structure of nodes, cells and fractures into files in ASCII format with detail explanations. This output is optional and can be helpful in code debugging.

Definition at line 898 of file ReadGridInit.c.

References cell, inpfile::filename, fracture, maindir, nfract, nnodes, node, material::numbcells, vertex::numneighb, and OpenFile().

Referenced by main().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ Xindex()

int Xindex	(	int	nodenum,
		int	nnp
	)

Functions returns the index of X coordination of intersection node

Definition at line 2254 of file TrackingPart.c.

References fracture, node, and particle.

Referenced by CalculateLagrangian(), CheckDistance(), and Moving2Center().

Here is the caller graph for this function:

◆ XindexC()

int XindexC	(	int	nodenum,
		int	ii
	)

Functions returns the index of X coordination of intersection node (cells)

Definition at line 776 of file VelocityReconstruction.c.

References cell, fracture, and node.

Referenced by AcrossIntersection(), BoundaryCells(), CornerVelocity(), and InOutFlowCell().

Here is the caller graph for this function:

◆ Yindex()

int Yindex	(	int	nodenum,
		int	nnp
	)

Functions returns the index of Y coordination of intersection node

Definition at line 2270 of file TrackingPart.c.

References fracture, node, and particle.

Referenced by CalculateLagrangian(), CheckDistance(), and Moving2Center().

Here is the caller graph for this function:

◆ YindexC()

int YindexC	(	int	nodenum,
		int	ii
	)

Functions returns the index of Y coordination of intersection node (cells)

Definition at line 791 of file VelocityReconstruction.c.

References cell, fracture, and node.

Referenced by AcrossIntersection(), BoundaryCells(), CornerVelocity(), and InOutFlowCell().

Here is the caller graph for this function:

Variable Documentation

◆ cell

struct element* cell

extern

DYNAMIC ARRAY OF TRIANGULAR CELLS in DFN mesh

Definition at line 42 of file main.c.

Referenced by AcrossIntersection(), AdjacentCells(), BoundaryCells(), CalculateCurrentDT(), CalculateLagrangian(), CalculatePosition3D(), CalculateWeights(), CheckDistance(), CorrectorStep(), FlowInWeight(), HalfPolygonVelocity(), InitPos(), InOutFlowCell(), InsideCell(), main(), Moving2Center(), Moving2NextCell(), Moving2NextCellBound(), OutputMarPlumDisp(), ParticleOutput(), ParticleTrack(), PredictorStep(), ReadDataFiles(), ReadInit(), SearchNeighborCells(), StreamlineRandomSampling(), TimeDomainRW(), WritingInit(), XindexC(), and YindexC().

◆ controlfile

char controlfile[120]

extern

Name of Control file with all inut parameters to dfnTrans, given by user at the command line

Definition at line 44 of file main.c.

Referenced by main().

◆ density

double density

extern

Flow density, defined by user

Definition at line 47 of file main.c.

Referenced by InitParticles_flux(), main(), ReadBoundaryNodes(), ReadPFLOTRANfile(), VelocityExteriorNode(), and VelocityInteriorNode().

◆ fehm

unsigned int fehm

extern

fehm=1 when FEHM flow solver is used

Definition at line 28 of file main.c.

Referenced by DarcyVelocity(), HalfPolygonVelocity(), and ReadDataFiles().

◆ flag_w

unsigned int flag_w

extern

Definition at line 38 of file main.c.

Referenced by InitPos(), and ParticleTrack().

◆ fracture

struct material* fracture

extern

DYNAMIC ARRAY OF FRACTURES

Definition at line 39 of file main.c.

Referenced by AdjacentCells(), BoundaryCells(), CalculatePosition3D(), CalculateVelocity3D(), CheckDistance(), CheckGrid(), Convertto2d(), Convertto3d(), Coordinations2D(), DarcyVelocity(), DefineBoundaryAngle(), HalfPolygonVelocity(), InitParticles_ones(), InitPos(), main(), Moving2NextCell(), Moving2NextCellBound(), NeighborCells(), ParticleOutput(), ParticleTrack(), ReadAperture(), ReadDataFiles(), ReadInit(), StreamlineRandomSampling(), TimeDomainRW(), WritingInit(), Xindex(), XindexC(), Yindex(), and YindexC().

◆ maindir

char maindir[125]

extern

The directory/path for particle tracking outputs, defined by user

Definition at line 43 of file main.c.

Referenced by CalculateVelocity3D(), DefineBoundaryAngle(), main(), OutputMarPlumDisp(), ParticleOutput(), ParticleTrack(), ReadBoundaryNodes(), and WritingInit().

◆ max_neighb

unsigned int max_neighb

extern

maximum number of nodes neighbours/connections

Definition at line 32 of file main.c.

Referenced by DarcyVelocity(), HalfPolygonVelocity(), ReadDataFiles(), ReadFEHMfile(), and ReadInit().

◆ ncells

unsigned int ncells

extern

total number of triangular elements in the DFN mesh

Definition at line 30 of file main.c.

Referenced by BoundaryCells(), InitPos(), ReadDataFiles(), and ReadInit().

◆ nfract

unsigned int nfract

extern

total number of fractures in the DFN mesh

Definition at line 31 of file main.c.

Referenced by Convertto2d(), Convertto3d(), Coordinations2D(), DefineBoundaryAngle(), ParticleTrack(), ReadAperture(), ReadDataFiles(), ReadInit(), and WritingInit().

◆ nnodes

unsigned int nnodes

extern

total number of nodes in the DFN mesh

Definition at line 29 of file main.c.

Referenced by CalculateVelocity3D(), CheckGrid(), Convertto2d(), Coordinations2D(), DarcyVelocity(), DefineBoundaryAngle(), DefineTimeStep(), ReadAperture(), ReadDataFiles(), ReadFEHMfile(), ReadInit(), ReadPFLOTRANfile(), and WritingInit().

◆ node

struct vertex* node

extern

DYNAMIC ARRAY OF NODES in DFN mesh

Definition at line 40 of file main.c.

Referenced by AcrossIntersection(), AdjacentCells(), BoundaryCells(), CalculateCurrentDT(), CalculateLagrangian(), CalculateVelocity3D(), CalculateWeights(), CheckDistance(), CheckGrid(), CompleteMixingRandomSampling(), Convertto2d(), Coordinations2D(), CornerVelocity(), DarcyVelocity(), DefineBoundaryAngle(), DefineTimeStep(), FlowInWeight(), HalfPolygonVelocity(), InitCell(), InitInMatrix(), InitInWell(), InitParticles_eq(), InitParticles_flux(), InitParticles_np(), InitPos(), InOutFlowCell(), InsideCell(), main(), Moving2Center(), Moving2NextCell(), Moving2NextCellBound(), NeighborCells(), ParticleOutput(), ParticleTrack(), PredictorStep(), ReadAperture(), ReadBoundaryNodes(), ReadDataFiles(), ReadFEHMfile(), ReadInit(), ReadPFLOTRANfile(), StreamlineRandomSampling(), TimeDomainRW(), VelocityExteriorNode(), VelocityInteriorNode(), WritingInit(), Xindex(), XindexC(), Yindex(), and YindexC().

◆ nodezonein

unsigned int* nodezonein

extern

pointer to the dynamic array with a list of in-flow boundary nodes

Definition at line 36 of file main.c.

Referenced by InitCell(), InitInWell(), InitParticles_flux(), InitParticles_np(), InitPos(), main(), ParticleTrack(), and ReadBoundaryNodes().

◆ nodezoneout

unsigned int* nodezoneout

extern

pointer to the dynamic array with a list of out-flow boundary nodes

Definition at line 37 of file main.c.

Referenced by main(), ParticleTrack(), and ReadBoundaryNodes().

◆ np

unsigned int np

extern

index of current particle, idex in particle's loop

Definition at line 34 of file main.c.

Referenced by AcrossIntersection(), CalculateCurrentDT(), CalculateLagrangian(), CalculatePosition3D(), CalculateWeights(), CheckDistance(), CorrectorStep(), FlowInWeight(), InitParticles_flux(), InOutFlowCell(), InsideCell(), Moving2NextCell(), Moving2NextCellBound(), NeighborCells(), ParticleOutput(), ParticleTrack(), PredictorStep(), SearchNeighborCells(), and TimeDomainRW().

◆ npart

unsigned int npart

extern

initial number of particles set up in the simulation

Definition at line 33 of file main.c.

Referenced by InitInMatrix(), InitParticles_eq(), InitParticles_flux(), InitParticles_np(), InitParticles_ones(), and InitPos().

◆ nzone_in

unsigned int nzone_in

extern

number of nodes in in-flow boundary face/zone

Definition at line 35 of file main.c.

Referenced by InitCell(), InitInWell(), InitPos(), and ReadBoundaryNodes().

◆ particle

struct contam* particle

extern

DYNAMIC ARRAY OF PARTICLES

Definition at line 41 of file main.c.

Referenced by AcrossIntersection(), CalculateCurrentDT(), CalculateLagrangian(), CalculatePosition3D(), CalculateWeights(), CheckDistance(), CorrectorStep(), FlowInWeight(), InitInMatrix(), InitInWell(), InitParticles_eq(), InitParticles_flux(), InitParticles_np(), InitParticles_ones(), InitPos(), InOutFlowCell(), InsideCell(), main(), Moving2Center(), Moving2NextCell(), Moving2NextCellBound(), NeighborCells(), ParticleOutput(), ParticleTrack(), PredictorStep(), SearchNeighborCells(), TimeDomainRW(), Xindex(), and Yindex().

◆ pflotran

unsigned int pflotran

extern

pflotran=1 when PFLOTRAN flow solver is used

Definition at line 27 of file main.c.

Referenced by DarcyVelocity(), HalfPolygonVelocity(), and ReadDataFiles().

◆ porosity

double porosity

extern

Fracture porosity, used in velocity reconstructions, defined by user

Definition at line 46 of file main.c.

Referenced by main(), VelocityExteriorNode(), and VelocityInteriorNode().

◆ saturation

double saturation

extern

Flow saturation, defined by user

Definition at line 50 of file main.c.

Referenced by main().

◆ thickness

double thickness

extern

One value for all fractures aperture (defined by user), used in case when fracture aperture is not provided by user

Definition at line 49 of file main.c.

Referenced by main(), and ReadDataFiles().

◆ timesteps

unsigned long int timesteps

extern

Max number of time steps used for each particles movements, defined by user

Definition at line 48 of file main.c.

Referenced by main(), and ParticleTrack().

◆ timeunit

double timeunit

extern

Time unit multiplier, converts calculated time/velocities according to required time units

Definition at line 51 of file main.c.

Referenced by main(), OutputMarPlumDisp(), ParticleTrack(), TimeFromMatrix(), VelocityExteriorNode(), and VelocityInteriorNode().

◆ totalFluxIn

double totalFluxIn

extern

Total Flow flux on in-flow boundary, calculated in the code

Definition at line 52 of file main.c.

Referenced by InitPos(), and ReadBoundaryNodes().

Data Structures

Macros

Functions

Variables

Macro Definition Documentation

◆ pi

Function Documentation

◆ AcrossIntersection()

◆ AdjacentCells()

◆ BoundaryCells()

◆ BoundaryLine()

◆ BVelocityDirection()

◆ CalculateCurrentDT()

◆ CalculateLagrangian()

◆ CalculatePosition3D()

◆ CalculateVelocity3D()

◆ CalculateWeights()

◆ ChangeFracture()

◆ CheckDistance()

◆ CheckGrid()

◆ CheckNewCell()

◆ CompleteMixingRandomSampling()

◆ Control_Data()

◆ Control_File()

◆ Control_File_Optional()

◆ Control_Param()

◆ Convertto2d()

◆ Convertto3d()

◆ Coordinations2D()

◆ CornerVelocity()

◆ CorrectorStep()

◆ DarcyVelocity()

◆ DefineAngle()

◆ DefineBoundaryAngle()

◆ DefineTimeStep()

◆ FinalPosition()

◆ FlowInWeight()

◆ HalfPolygonVelocity()

◆ InitCell()

◆ InitInMatrix()

◆ InitInWell()

◆ InitParticles_eq()

◆ InitParticles_flux()

◆ InitParticles_np()

◆ InitParticles_ones()

◆ InitPos()

◆ InOutFlowCell()

◆ InsideCell()

◆ MatrixProducts()

◆ Moving2Center()

◆ Moving2NextCell()

◆ Moving2NextCellBound()

◆ NeighborCells()

◆ OpenFile()

◆ OutputMarPlumDisp()

◆ OutputVelocities()

◆ ParticleOutput()

◆ ParticleTrack()

◆ PredictorStep()

◆ ReadAperture()

◆ ReadBoundaryNodes()

◆ ReadDataFiles()

◆ ReadFEHMfile()

◆ ReadInit()

◆ ReadPFLOTRANfile()

◆ SearchNeighborCells()

◆ StreamlineRandomSampling()

◆ String_Compare()

◆ TimeDomainRW()

◆ TimeFromMatrix()

◆ Velocity3D()

◆ VelocityExteriorNode()

◆ VelocityInteriorNode()

◆ WritingInit()

◆ Xindex()

◆ XindexC()

◆ Yindex()

◆ YindexC()

Variable Documentation

◆ cell
