#include <stdio.h>
#include <search.h>
#include <stdlib.h>
#include <math.h>
#include <string.h>
#include "FuncDef.h"
#include <unistd.h>
#include <time.h>

Include dependency graph for InitialPartPositions.c:

Data Structures
struct	inpfile

struct	posit3d

Functions
int	InitPos ()

int	InitCell ()

int	InitParticles_np (int k_current, int firstnd, int lastnd, int parts_fracture, int first_ind, int last_ind)

int	InitParticles_eq (int k_current, int firstn, int lastn, double parts_dist, int first_ind, int last_ind)

int	InitParticles_ones (int k_current, double inter_p[][4], int fracture_n, int parts_fracture, int ii, double thirdcoor, int zonenumb_in, int first_ind, int last_ind)

void	FlowInWeight (int numberpart)

void	InitInMatrix ()

double	TimeFromMatrix (double pdist)

int	InitParticles_flux (int k_current, int first_ind, int last_ind, double weight_p)

int	InitInWell (int node_part)

Function Documentation

◆ FlowInWeight()

void FlowInWeight ( int numberpart )

Function calculates particle's in-flow flux weight. Used in option #1, #2, #3.

Definition at line 747 of file InitialPartPositions.c.

References contam::cell, cell, contam::fl_weight, InitCell(), node, element::node_ind, np, vertex::numneighb, particle, and contam::weight.

Referenced by ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ InitCell()

int InitCell ( )

Function performs a search to find cell Id where the particle was initially placed.

Definition at line 542 of file InitialPartPositions.c.

References vertex::cells, InsideCell(), node, nodezonein, vertex::numneighb, and nzone_in.

Referenced by FlowInWeight(), and ParticleTrack().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ InitInMatrix()

void InitInMatrix ( )

Function performs data reading from files for Option #5, init_matrix. In this option particles are placed at random positions in matrix, the time to move from initial position to nearest fracture is calculated in function TimeFromMatrix.

Input files ParticleInitCoordR.dat and ClosestNodeR.inp provide particles initial positions at matrix and te closes node ID at DFN mesh, respectively.

Definition at line 832 of file InitialPartPositions.c.

References contam::cell, Control_File(), vertex::coord, vertex::coord_xy, inpfile::filename, contam::fl_weight, vertex::fracture, contam::fracture, contam::intcell, node, npart, OpenFile(), particle, contam::position, contam::pressure, contam::prev_pos, contam::time, TimeFromMatrix(), contam::velocity, and contam::weight.

Referenced by InitPos().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ InitInWell()

int InitInWell ( int node_part )

Definition at line 1028 of file InitialPartPositions.c.

References vertex::aperture, contam::cell, vertex::coord_xy, contam::fl_weight, vertex::fracture, contam::fracture, node, nodezonein, nzone_in, particle, contam::position, contam::pressure, contam::time, and contam::velocity.

Referenced by InitPos().

Here is the caller graph for this function:

◆ InitParticles_eq()

int InitParticles_eq	(	int	k_current,
		int	firstn,
		int	lastn,
		double	parts_dist,
		int	first_ind,
		int	last_ind
	)

Function defines particles initial positions at a single fracture edge, using calculated before distance between particles. Option #2, init_eqd.

Definition at line 623 of file InitialPartPositions.c.

References vertex::coord_xy, contam::fl_weight, vertex::fracture, contam::fracture, contam::intcell, node, npart, particle, contam::position, contam::pressure, contam::time, and contam::velocity.

Referenced by InitPos().

Here is the caller graph for this function:

◆ InitParticles_flux()

int InitParticles_flux	(	int	k_current,
		int	first_ind,
		int	last_ind,
		double	weight_p
	)

Function defines particle's initial positions at single fracture edge in Option #6. Particles are placed according to input flux weights. In this case, all the particles have the same flux weight, but number of particles per fracture edge depends on in-flow flux of this fracture.

Definition at line 939 of file InitialPartPositions.c.

References contam::cell, vertex::coord_xy, density, contam::fl_weight, vertex::flux, vertex::fracture, contam::fracture, contam::intcell, node, nodezonein, np, npart, vertex::numneighb, particle, contam::position, contam::pressure, contam::time, and contam::velocity.

Referenced by InitPos().

Here is the caller graph for this function:

◆ InitParticles_np()

int InitParticles_np	(	int	k_current,
		int	firstnd,
		int	lastnd,
		int	parts_fracture,
		int	first_ind,
		int	last_ind
	)

Function defines particle's initial positions on a single fracture edge. Option #1, init_nf

Definition at line 578 of file InitialPartPositions.c.

References vertex::coord_xy, contam::fl_weight, vertex::fracture, contam::fracture, contam::intcell, node, nodezonein, npart, particle, contam::position, contam::pressure, contam::time, and contam::velocity.

Referenced by InitPos().

Here is the caller graph for this function:

◆ InitParticles_ones()

int InitParticles_ones	(	int	k_current,
		double	inter_p[][4],
		int	fracture_n,
		int	parts_fracture,
		int	ii,
		double	thirdcoor,
		int	zonenumb_in,
		int	first_ind,
		int	last_ind
	)

Function defines particles initial positions in option #3, where user defines region at in-flow boundary face for particles.

Definition at line 668 of file InitialPartPositions.c.

References contam::fl_weight, contam::fracture, fracture, contam::intcell, npart, particle, contam::position, contam::pressure, material::rot2mat, contam::time, and contam::velocity.

Referenced by InitPos().

Here is the caller graph for this function:

◆ InitPos()

int InitPos ( )

Function defines the required option of particles initial positions defined at input control file; calculates number of particles, allocates memory.

First option init_nf: equal number of particles on every boundary edge regardless of edge length

Second option init_eqd: calculate total length of boundary edges; define the distance between particles and place particles equidistant from each other on all edges

Third option init_oneregion: user specifies a region and all particles start from the fracture edges that located inside the region

Fourth option init_random: particles will be set randomly over all fractures surfaces; in this case the particles are weighted acoording to the aperture

5th option init_matrix: particles are set randomly in rock matrix, their time from initial positions is calculated, then particles move through fractures to out-flow boundary. This option requires preprocessing; the script RandomPositGener.py will provide necessary input files

Sixth option init_flux: place particles according to input fluxes. Each particle has the same flux weight. The number of particles are placed propportionally to inflow flux on each cell and fracture edge.

Definition at line 21 of file InitialPartPositions.c.

References vertex::aperture, contam::cell, cell, Control_Data(), Control_File(), Control_File_Optional(), Control_Param(), vertex::coord, inpfile::filename, contam::fl_weight, inpfile::flag, flag_w, vertex::fracture, element::fracture, contam::fracture, fracture, InitInMatrix(), InitInWell(), InitParticles_eq(), InitParticles_flux(), InitParticles_np(), InitParticles_ones(), InsideCell(), Moving2Center(), ncells, node, element::node_ind, nodezonein, npart, nzone_in, inpfile::param, particle, contam::pressure, contam::time, totalFluxIn, and contam::velocity.
