pydfnworks.dfnGraph.graph_transport Namespace Reference

Data Structures
class	Particle

Functions
def	create_neighbor_list (Gtilde)
def	prepare_output_files (partime_file, frac_id_file)
def	dump_particle_info (particles, partime_file, frac_id_file)
def	track_particle (data)
def	run_graph_transport (self, Gtilde, nparticles, partime_file, frac_id_file, frac_porosity=1.0, tdrw_flag=False, matrix_porosity=0.02, matrix_diffusivity=1e-11)

Detailed Description

.. module:: graph_transport.py
   :synopsis: simulate transport on a pipe network representaiton of a DFN
.. moduleauthor:: Shriram Srinivasan <shrirams@lanl.gov>

Function Documentation

create_neighbor_list()

def pydfnworks.dfnGraph.graph_transport.create_neighbor_list

(

Gtilde

)

 Create a list of downstream neighbor vertices for every vertex on NetworkX graph obtained after running graph_flow

Parameters
----------
    Gtilde: NetworkX graph
        obtained from output of graph_flow

Returns
-------
    dict : nested dictionary.

Notes
-----
dict[n]['child'] is a list of vertices downstream to vertex n
dict[n]['prob'] is a list of probabilities for choosing a downstream node for vertex n

Definition at line 20 of file graph_transport.py.

Referenced by pydfnworks.dfnGraph.graph_transport.run_graph_transport().

Here is the caller graph for this function:

dump_particle_info()

def pydfnworks.dfnGraph.graph_transport.dump_particle_info	(		particles,
			partime_file,
			frac_id_file
	)

 If running graph transport in parallel, this function dumps out all the
    particle information is a single pass rather then opening and closing the
    files for every particle


    Parameters
    ----------
        particles : list
            list of particle objects

        partime_file : string
            name of file to  which the total travel times and lengths will be written for each particle

        frac_id_file : string
            name of file to which detailed information of each particle's travel will be written

    Returns
    -------
        pfailcount : int
            Number of particles that do not exit the domain

Definition at line 284 of file graph_transport.py.

References pydfnworks.dfnGraph.graph_transport.prepare_output_files().

Referenced by pydfnworks.dfnGraph.graph_transport.run_graph_transport().

Here is the call graph for this function:

Here is the caller graph for this function:

prepare_output_files()

def pydfnworks.dfnGraph.graph_transport.prepare_output_files	(		partime_file,
			frac_id_file
	)

 opens the output files partime_file and frac_id_file and writes the
    header for each

    Parameters
    ----------

        partime_file : string
            name of file to  which the total travel times and lengths will be written for each particle

        frac_id_file : string
            name of file to which detailed information of each particle's travel will be written

    Returns
    -------
        None

Definition at line 242 of file graph_transport.py.

Referenced by pydfnworks.dfnGraph.graph_transport.dump_particle_info(), and pydfnworks.dfnGraph.graph_transport.run_graph_transport().

Here is the caller graph for this function:

run_graph_transport()

def pydfnworks.dfnGraph.graph_transport.run_graph_transport	(		self,
			Gtilde,
			nparticles,
			partime_file,
			frac_id_file,
			frac_porosity = 1.0,
			tdrw_flag = False,
			matrix_porosity = 0.02,
			matrix_diffusivity = 1e-11
	)

 Run  particle tracking on the given NetworkX graph

Parameters
----------
    self : object
        DFN Class

    Gtilde : NetworkX graph
        obtained from graph_flow

    nparticles: int
        number of particles

    partime_file : string
        name of file to  which the total travel times and lengths will be written for each particle

    frac_id_file : string
        name of file to which detailed information of each particle's travel will be written

    frac_porosity: float
        porosity of fracture, default is 1.0
    tdrw_flag : Bool
        if False, matrix_porosity, matrix_diffusivity are ignored
    matrix_porosity: float
        default is 0.02
    matrix_diffusivity: float
        default is 1e-11 in SI units

Returns
-------

Notes
-----
Information on individual functions is found therein

Definition at line 394 of file graph_transport.py.

References pydfnworks.dfnGraph.graph_transport.create_neighbor_list(), pydfnworks.dfnGraph.graph_transport.dump_particle_info(), and pydfnworks.dfnGraph.graph_transport.prepare_output_files().

Here is the call graph for this function:

track_particle()

def pydfnworks.dfnGraph.graph_transport.track_particle

(

data

)

 Tracks a single particle through the graph

    all input parameters are in the dictionary named data

    Parameters
    ----------

        Gtilde : NetworkX graph
            obtained from graph_flow

        nbrs_dict : dict
            see function  create_neighbor_list

        frac_porosity: float
            porosity of fracture, default is 1.0

        tdrw_flag : Bool
            if False, matrix_porosity, matrix_diffusivity are ignored

        matrix_porosity: float
            default is 0.02

        matrix_diffusivity: float
            default is 1e-11 m^2/s

    Returns
    -------
        particle : object
            particle trajectory information

Definition at line 352 of file graph_transport.py.
